Interface Cable (IFC)
Hier finden Sie Kabel zur Display-Schnittstelle. Gängige Schnittstellen sind LVDS, TTL, V-by-One und mehr.
| Art. No. | Name | Length (mm) | Interface | CN1 Vendor | CN1 Part No. | CN2 Vendor | CN2 Part No. | CN3 Vendor | CN3 Part No. | Image | Schema |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 188-00013 | 3231-6.4-250 | 250 | TTL 18-bit | JWT | Fe-Leiste 32pol. RM2x2 | Hirose | DF9C-31S-1V | Bild anzeigen | Download | ||
| 188-00434 | IFC-LQ084S3DG01-250 | 250 | TTL 18-bit | JWT | Fe-Leiste 32pol. RM2x2 | Hirose | DF19G-30P-1H | Noch kein Bild | Download | ||
| 188-00448 | IFC-G185XW01V1_Lock-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Bild anzeigen | Download | ||
| 188-00449 | IFC-LQ150X1LG11-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF14-30S-1.25C | Molex | 51004-0700 | Bild anzeigen | Download |
| 188-00478 | IFC-MG150X06-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF14-20S-1.25C | Bild anzeigen | Download | ||
| 188-00479 | IFC-M170EN05-250 | 250 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Bild anzeigen | Download | ||
| 188-00500 | IFC-MHT12X21-250 | 250 | LVDS 18-bit | Hirose | DF14-30S-1.25C | Hirose | DF19-20S-1C | Bild anzeigen | Download | ||
| 188-00507 | IFC-V320B1-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Noch kein Bild | Download | ||
| 188-00519 | IFC-G121S1-L01-250 | 250 | LVDS 18-bit | Hirose | DF14-30S-1.25C | JAE | FI-SE20ME | Noch kein Bild | Download | ||
| 188-00520 | IFC-G104X1-L01-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Bild anzeigen | Download | ||
| 188-00521 | IFC-T260XW02-170 | 170 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-E30H | Noch kein Bild | Download | ||
| 188-00522 | IFC-T260XW02-500 | 500 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-E30H | Noch kein Bild | Download | ||
| 188-00537 | IFC-HX104X01-MT-250 | 250 | LVDS 18-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Molex | 51021-0700 | Noch kein Bild | Download |
| 188-00541 | IFC-G121X1-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-SE20ME | Bild anzeigen | Download | ||
| 188-00542 | IFC-G150XG01-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF14-20S-1.25C | Noch kein Bild | Download | ||
| 188-00671 | IFC-V315H3-LE4-250 | 250 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-RE51HL | Bild anzeigen | Download | ||
| 188-00677 | IFC-T-51576D121J-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-S20S | Bild anzeigen | Download | ||
| 188-00678 | IFC-G104S1-L01-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF19-20S-1C | Bild anzeigen | Download | ||
| 188-00679 | IFC-M170EN05_Lock-250 | 250 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Bild anzeigen | Download | ||
| 188-02106 | IFC-G121I1MT-130 | 130 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Molex | 51021-0700 | Bild anzeigen | Download |
| 188-02306 | IFC-G121I1-L01-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30H | Molex | 51004-0700 | Bild anzeigen | Download |
| 188-02308 | IFC-M170EN05_LOCK-500 | 500 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Bild anzeigen | Download | ||
| 188-02309 | IFC-G150XGEL04-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF14-20S-1.25C | Bild anzeigen | Download | ||
| 188-02310 | IFC-G150XGEL04-150 | 150 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF14-20S-1.25C | Bild anzeigen | Download | ||
| 188-02312 | IFC-G065VN01V2-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF19-20S-1C | Bild anzeigen | Download | ||
| 188-02509 | IFC-AM19201200B1-250 | 250 | LVDS 24-bit / Dual | IPEX | IPEX-20453-040T-11 | Hirose | DF14-30S-1.25C | Molex | 51021-0800 | Noch kein Bild | Download |
| 188-02511 | IFC-AM1280800N3TZQW-44-250 | 250 | LVDS 24-bit | IPEX | IPEX-20453-040T-12 | Hirose | DF14-30S-1.25C | Molex | 51021-0800 | Noch kein Bild | Download |
| 188-02634 | IFC_M170EN05-Lock_300 | 300 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Noch kein Bild | Download | ||
| 188-02637 | IFC_AM800480RCTMW-A1H_DCMR44-250 | 250 | LVDS 18-bit | Hirose | DF14-30S-1.25C | Hirose | DF19G-20S-1C | Molex | 51021-0800 | Noch kein Bild | Download |
| 188-02640 | IFC-Y-AM800480RSTMQW-60-250 | 250 | LVDS 18-bit | Hirose | DF14-30S-1.25C | Hirose | DF19-20S-1C | Molex | 51004-0700 | Noch kein Bild | Download |
| 188-02645 | IFC_G121S1-L01-700 | 700 | LVDS 18-bit | Hirose | DF14-30S-1.25C | JAE | FI-SE20ME | Noch kein Bild | Download | ||
| 188-02647 | IFC_M185BGE_L22-500 | 500 | LVDS 24-bit | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Noch kein Bild | Download | ||
| 188-02648 | IFC_LTM190M2-L31-1000 | 1000 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | JAE | FI-X30HL | Noch kein Bild | Download | ||
| 188-02659 | IFC-G156HTN02.0-250 | 250 | LVDS 24-bit / Dual | Hirose | DF14-30S-1.25C | Hirose | DF14-30S-1.25C | Noch kein Bild | Download | ||
| 188-02668 | IFC-AM-1280800P3TZQW-00H-250 | 250 | LVDS 24-bit | Hirose | DF14-30S-1.25C | Hirose | DF19-20S-1C | Noch kein Bild | Download | ||
